SO 810X-AI Electronic Sentinel
Multi-spectrum EO/IR Positioning PTZ System
SO 810X AI PTZ camera system is a multi-spectral electro-optical positioning system designed to support long range observation and situational awareness in complex low altitude environments. It provides continuous monitoring and precise visual tracking for aerial targets such as unmanned aerial vehicles (UAVs), ensuring effective detection, identification, and response in security protection zones. The system assists in maintaining airspace security and enhances perimeter defense capability under all weather and day-night conditions.
Multispectral EO/IR imaging
Integrated thermal camera (LWIR/MWIR) and UHD visible camera providing clear target observation and monitoring in day, night and harsh weather conditions.
Long-range UAV detection
Designed for low-altitude airspace security, enabling long-distance detection, recognition and tracking of drones, vehicles and human targets.
High precision PTZ positioning
High-precision closed-loop brushless motor drive with up to 1000°/s acceleration and ±0.01° positioning accuracy for fast target tracking.
Intelligent target detection
Support human, vehicle, vessel and UAV detection, along with perimeter intrusion, wandering and boundary crossing analysis.
Advanced video compression
Support H.265 / H.264 / MJPEG compression, multiple stream outputs and adjustable encoding parameters for efficient bandwidth usage.
Flexible network integration
Support ONVIF, Web API and multiple network protocols, enabling seamless integration with security platform.
Rugged All-Weather Design
All-metal structure with IP67 protection, lightning protection and reliable operation from −40°C to +70°C.
Intelligent Maintenance Features
Equipped with automatic wiper sensing, defogging, de icing and heating, ensuring clear imaging in extreme environments.
Thermal Imaging Camera
Detector
Array Format/Pixel Pitch
NETD
Image Frame Rate
Pseudo color
Vox Uncooled Focal Plane Arrays
640x512/12µm
≤35mK@25°C,F/1.0s)
50Hz
20 Psedudo Color palettes changeable
Brightness & Contrast
Polarity
Color Palette
Digital Zoom
Focal Length
Manual/Auto0/Auto
Black hot/White hot
20
1.0-8.0x continuing zooming
100 mm F/1.0
FOV
Focus
Image Stabilization
4.38° * 3.51°
Automatic, manual
Electronic Image Stabilization (EIS)
Visible Light Camera
Image sensor
Effective Pixels
Minimum Illumination
Focal Length
Aperture Range
Shutter time
Horizontal Field of View
Working Distance
Zoom Speed
WDR
De-fog
Image Stabilization
Noise Reduction
1/2" Progressive Scan CMOS, 4MP
3840(H) x 2160(V), 8MP
Color: 0.005Lux@F1.5; W/B: 0.0001Lux@F1.5 (IR on)
10-550mm; 55x optical zoom
F1.5-F5.5
1/25-1/100,000s, support Slow Shutter
58.40° to 1.20° (wide-tele)
100mm-2000mm(wide-tele)
Approx. 9s(wide-tele)
120 dB
Yes
Electronic Image Stabilization (EIS)
Yes (configurable 3D/2D)
Video & Audio
H.265 /H.264 /MJPEG
G.711 a/G.711 u/G.722.1/G.726/MP2L2/AAC/PCM
Thermal:
50Hz: 25fps (1280 × 1024, 1280 × 720, 640×512)
Visible:
50Hz: 25fps (3840×2160, 2688×1520, 1920×1080,
1280 × 960, 1280 × 720)
60Hz: 30fps (3840×2160, 2688×1520, 1920×1080,
1280 × 960, 1280 × 720)
BLC /HLC /WDR (120dB)
Auto, ATW, Indoor, Outdoor, Manual
3 streams
Automatic/aperture priority/shutter priority/manual exposure
Auto focus/one-time focus/manual focus
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,
RTCP,NTP,SMTP,SNMP,IPv6
ONVIF(PROFILE S,PROFILE G)
Compression
Audio Compression
Main Stream
BLC
White Balance
Streaming
Exposure Mode
Focus Control
Protocol
Interface Protocol
Visible-light drone detection
Thermal drone detection
PTZ
360° endless
0.01°-200°/s
-90°-90° auto reverse
0.01°-150°/s
255
16 patrols, up to 32 pre-sets per patrol
1000°/s²
Support
Pelco D/2400/4800/9600(default)/19200 Optional
Pan Range
Pan Speed
Tilt Range
Tilt Speed
Number of Pre-set
Patrol
Acceleration
Power Loss Recovery
Communication Protocol
Laser Rangerfinder
1535 ± 5nm
3Km
Laser Wavelength
Measurement Distancel
Event
Support
Support
Perimeter(human & vehicle classification), Fire detection,
Ship tracking, Aircraft detect
Video taking/Image capture/Email/Linked PTZ/Alarm output
Fire Point Detection
Intelligent Video Taking
Intelligent Detection
Alarm Linkage
General
DC 24V, 200W(Max)
1 RJ45 100M Ethernet port
Built-in memory card slot, support Micro SD / SDHC / SDXC
card, up to 256GB
1/1
1/1
Rs422/Rs485, PELCO-D
1 channel Thermal Imaging video stream and 1 channel HD
video stream are optional with a same IP address via Rj45
-40-70°C
IP67, TVS 6000V Lighting protection, surge protection
Top Mounting
491.5×235.3×378.1mm
19Kg
Power
Ethernet
On-board Storage
Alarm Input/Output
Audio Input/Output
COM/Protocol
Video Output
Working temperature
Protection Level
Mount Option
Dimension
Weight
